Chapter 4 Parameters|
4-14 Revision August 2008, 2ELE, V1.02
Parameter Explanation Settings
Factory
Setting
Customer
14: Phase-Loss (PHL)
15: Reserved
16: Auto Acel/Decel failure (CFA)
17: SW/Password protection (codE)
18: Power Board CPU WRITE failure (cF1.0)
19: Power Board CPU READ failure (cF2.0)
06.10
Third Most Recent
Fault Record
20: CC, OC Hardware protection failure
(HPF1)
21: OV Hardware protection failure (HPF2)
22: GFF Hardware protection failure (HPF3)
06.11
Fourth Most Recent
Fault Record
23: OC Hardware protection failure (HPF4)
24: U-phase error (cF3.0)
25: V-phase error (cF3.1)
06.12
Fifth Most Recent
Fault Record
26: W-phase error (cF3.2)
27: DCBUS error (cF3.3)
28: IGBT Overheat (cF3.4)
29: Reserved
30: Reserved
31: Reserved
32: ACI signal error (AErr)
33: Reserved
34: Motor PTC overheat protection (PtC1)
35-40: Reserved
Group 7 Motor Parameters
Parameter Explanation Settings
Factory
Setting
Customer
07.00 Motor Rated Current 30 %FLA to 120% FLA FLA
07.01
Motor No-Load
Current
0%FLA to 99% FLA 0.4*FLA
