Chapter 4 Parameters|
4-10 Revision August 2008, 2ELE, V1.02
Parameter Explanation Settings
Factory
Setting
Customer
9: External base block 4
10: Up: Increment master frequency
04.08 Multi-function Input
Terminal (MI6)
11: Down: Decrement master frequency
12: Counter Trigger Signal
13: Counter reset
14: E.F. External Fault Input
15: PID function disabled
16: Output shutoff stop
17: Parameter lock enable
18: Operation command selection (external
terminals)
19: Operation command selection(keypad)
20: Operation command
selection(communication)
21: FWD/REV command
22: Source of second frequency command
04.09
Multi-function Input
Contact Selection
Bit0:MI1
Bit1:MI2
Bit2:MI3
Bit3:MI4
Bit4:MI5
Bit5:MI6
0:N.O., 1:N.C.
P.S.:MI1 to MI3 will be invalid when it is 3-
wire control.
0
04.10
Digital Terminal
Input Debouncing
Time
1 to 20 (*2ms) 1
04.11
Min AVI Voltage 0.0 to 10.0V
0.0
04.12
Min AVI Frequency 0.0 to 100.0%
0.0
04.13
Max AVI Voltage 0.0 to 10.0V
10.0
04.14
Max AVI Frequency 0.0 to 100.0%
100.0
