Chapter 4 Parameters|
Revision August 2008, 2ELE, V1.02 4-5
Group 2 Operation Method Parameters
Parameter Explanation Settings
Factory
Setting
Customer
02.00
Source of First
Master Frequency
Command
0: Digital keypad UP/DOWN keys or Multi-
function Inputs UP/DOWN. Last used
frequency saved.
1: 0 to +10V from AVI
2: 4 to 20mA from ACI
3: RS-485 (RJ-45) communication
4: Digital keypad potentiometer
1
0: Digital keypad
1: External terminals. Keypad STOP/RESET
enabled.
2: External terminals. Keypad STOP/RESET
disabled.
3: RS-485 (RJ-45) communication. Keypad
STOP/RESET enabled.
02.01
Source of First
Operation
Command
4: RS-485 (RJ-45) communication. Keypad
STOP/RESET disabled.
1
0: STOP: ramp to stop; E.F.: coast to stop
1: STOP: coast to stop; E.F.: coast to stop
2: STOP: ramp to stop; E.F.: ramp to stop
02.02 Stop Method
3: STOP: coast to stop; E.F.: ramp to stop
0
02.03
PWM Carrier
Frequency
Selections
2 to 12kHz 8
0: Enable forward/reverse operation
1: Disable reverse operation 02.04
Motor Direction
Control
2: Disabled forward operation
0
0: Disable. Operation status is not changed
even if operation command source Pr.02.01
is changed.
1: Enable. Operation status is not changed
even if operation command source Pr.02.01
is changed.
02.05 Line Start Lockout
2: Disable. Operation status will change if
operation command source Pr.02.01 is
changed.
1
