Appendix B Accessories|
B-26
Revision August 2008, 2ELE, V1.02
B.9.2 DIN Rail: MKEL-DRA (Only for frame A)
Dimensions
This DIN rail (MKEL-DRA) is only for frame A. For frame B, it is shipped with DIN rail (MKEL-DRB).
Refer to chapter 1.3 for VFD-EL dimension.
NOTE
Frame A: VFD002EL11A/21A/23A, VFD004EL11A/21A/23A/43A, VFD007EL21A/23A/43A,
VFD015EL23A/43A
Frame B: VFD007EL11A, VFD015EL21A, VFD022EL21A/23A/43A, VFD037EL23A/43A
