B.3 fuse specification chart – Delta Electronics AC Motor Drive VFD-EL User Manual
Page 183
Appendix B Accessories|
B-8
Revision August 2008, 2ELE, V1.02
B.3 Fuse Specification Chart
Smaller fuses than those shown in the table are permitted.
Line Fuse
Model
I (A)
Input
I (A)
Output
I (A)
Bussmann P/N
VFD002EL11A 6.4 1.6
15
JJN-15
VFD002EL21A 4.9 1.6
10
JJN-10
VFD002EL23A 1.9 1.6
5
JJN-6
VFD004EL11A 9 2.5 20
JJN-20
VFD004EL21A 6.5 2.5
15
JJN-15
VFD004EL23A 2.7 2.5
5
JJN-6
VFD004EL43A 1.8 1.5
5
JJS-6
VFD007EL11A 18 4.2
30
JJN-30
VFD007EL21A 9.3 4.2
20
JJN-20
VFD007EL23A 4.9 4.2
10
JJN-10
VFD007EL43A 3.2 2.5
5
JJS-6
VFD015EL21A 15.7 7.5
30
JJN-30
VFD015EL23A 9 7.5 20
JJN-20
VFD015EL43A 4.3 4.2
10
JJS-10
VFD022EL21A 24 11
50
JJN-50
VFD022EL23A 15 11
30
JJN-30
VFD022EL43A 7.1 5.5
15
JJS-15
VFD037EL23A 20.6 17
40
JJN-40
VFD037EL43A 9.0 8.2
20
JJS-20
