Chapter 4 Parameters|
Revision August 2008, 2ELE, V1.02 4-9
Parameter Explanation Settings
Factory
Setting
Customer
03.10 Reserved
03.11
Brake Release
Frequency
0.00 to 20.00Hz 0.00
03.12
Brake Engage
Frequency
0.00 to 20.00Hz 0.00
03.13
Display the Status of
Relay
Read only ##
Group 4 Input Function Parameters
Parameter Explanation Settings
Factory
Setting
Customer
04.00
Keypad
Potentiometer Bias
0.0 to 100.0 % 0.0
04.01
Keypad
Potentiometer Bias
Polarity 0: Positive bias
1: Negative bias
00
04.02
Keypad
Potentiometer Gain
0.1 to 200.0 % 100.0
0: No negative bias command
04.03
Keypad
Potentiometer
Negative Bias,
Reverse Motion
Enable/Disable
1: Negative bias: REV motion enabled
0
0: 2-wire: FWD/STOP, REV/STOP
1: 2-wire: FWD/REV, RUN/STOP
04.04 2-wire/3-wire
Operation Control
Modes
2: 3-wire operation
0
0: No function 1
1: Multi-Step speed command 1
04.05 Multi-function Input
Terminal (MI3)
2: Multi-Step speed command 2
3: Multi-Step speed command 3 2
4: Multi-Step speed command 4
04.06 Multi-function Input
Terminal (MI4)
5: External reset
6: Accel/Decel inhibit 3
7: Accel/Decel time selection command
04.07 Multi-function Input
Terminal (MI5)
8: Jog Operation
