Repairs Parts
PARTS LIST FOR CRAFTSMAN 10" ELECTRONIC RADIAL SAW
MODEL NOS. 113.197411,113.197511 AND 113.197611
Always order by Part Number - Not by Key Number
FIGURE 8 - CABINET ASSEMBLY FOR MODEL 113.197611
Key
No
Part
No.
Description
Key
No
Part
No.
Description
1 60314 Screw, Truss Hd 1/4-20 x 1/2 15
_
Drawer Assembly 6 in.
2 815898 Skirt 44" (see Fig. 10)
3 815892 Support, Center Rear 16
—
Drawer Assembly 10 in.
4 STD541025 *Nut, Hex 1/4-20 (see Fig. 10)
5 STD551225 ’ Lockwasher, External 1 /4 17 815942 Stiffener, Shelf
6 815893 Support, Upper 18 815896 Caster
7 815890 Bracket, Stand Slide 19 815993 Support, Caster
8 815886 Support, Front Center 2 0 815991 Support, Under
9 817151 Panel, Side R.H. 21
—
Foot Assembly, L.H.
1 0 - Drawer Assembly, 3 in. (see Fig. 7)
(see Fig. 10) 22 817150 Panel, Side L.H.
11 — Foot Assembly, R.H. 23 815889 Shelf, Lower 44 in.
(see Fig. 7) 24 815891 Support, Lower
12 802392-36 Spacer 25 816336 Stiffener - Shelf Rear
13 805529-5 Screw, Truss Hd
1/4-20 X 1
14 815888 Bracket, Center Slide
Standard Hardware item May Be Purchased Locally.
97
