Digital Display
2. Turn display on.
3. Push MITER button, then push REF
SET button. Display will read:
4. Push BEVEL button, then push REF
SET button. Display will read:
5. Push ELEV button, then push REF
SET button. Display will read:
Set Zero Reference Point For In
Rip
1. Put fence in front position and lock
table locks.
2. Lock blade in in-rip position (blade
towards column, motor towards table
front).
3. Unlock rip lock, push blade against
fence, and lock rip lock.
4. Push RIP button, then push REF SET
button. Display should read:
If it reads O-RIP instead of RIP,
push
RIP button then push REF SET button.
If display reads 10.00 instead of .00,
push
REF SET button.
Set Zero Reference Point For
Out-Rip
1.
Unlock rip lock and pull blade away
from fence.
2. Unlock table locks, move fence to rear
position, and lock table locks.
3. Lock blade in out-rip position (motor
towards column, blade towards table
front).
n
MIT
.u
n
REV
.u
n n
ELE
.u u
n n
RIP
.u
u
52
