Controls
Rip
Lock
Swivel
Lock
Rip Ix)ck
Swivel Lock
Frees carriage to move along
radial arm; locks in position
Frees blade carriage to rotate
between rip and crosscut posi
tions; locks in position
Operation/Commen/i'
Pull to unlock, push to lock
Lock before ripping
Pull to unlock; push to lock
Hold in unlocked position
while moving blade carnage
35
