Repair Parts
PARTS LIST FOR CRAFTSMAN 10" ELECTRONIC RADIAL SAW
MODEL NOS. 113.197411 AND 113.197611 AND 113.197511
Always order by Part Number - Not by Key Number
FIGURE 3 - YOKE AND MOTOR ASSEMBLY
Key
No
Part
No.
Description
Key
No
Part
No.
Description
1
_
Yoke Assembly (see Figure 4) 15 STD551012 ‘Washer, 17/64 x 9/16 x 1/16
2 818922 Screw, Flat Hd 16 818888 • Motor (Complete) (See Fig. 5)
Plastite No. 8 X 1 17 STD510802 * Screw, Pan Hd
3 818202 Handle, Yoke Type'T' 8-32x5/16
4 815678 Washer, Shaft 18 815802 Guide, Bevel Reader
5 815679-1 Pin, Index 19 818197 Plate, Index
6 STD551043 ‘Washer, .505 x 7/8 x 1/16 20 815751 Encoder, Bevel
7 815791 Spring, Bevel 21 STD601105 * Screw, Hex Washer Hd
8 818154 Lever. Bevel Lock Type ‘T’10-32 X 1/2
9 815813 Nut, Square 1/2-13 22 STD551010 ’Washer, 3/16x3/8x1/32
10 815836 Wedge, Bevel Spring 23 508153 Shaft, Support w/Plate
11 818204 Cover, Yoke 24 30495 Nut, Shaft
12 815799 Plug, Yoke 25 62498 Collar, Blade
13 806828 Screw, Pan Hd 26 9-32668 tBlade, Saw
Type “T" 1 /4-20
X
1 /2 27 805839-1 Nut, Lock 1/2-13
14 815992-1 Screw, Soc. Hd Type "TT"
1 /4-20
X
5/8
* Standard Hardware Item may be Purchased Locally.
tSiock Item may be secured Through the Hardware Department of Most Sears Retail or Catalog Order Houses.
• Any attempt to repair this motor may result in unit misalignment and create a HAZARD unless repair is
done by a qualified service technician. Do not loosen the three screws holding the motor support to the motor.
This assembly is factory aligned. Repair service is available at your nearest Sears Store.
89
