Repair Parts
PARTS LIST FOR CRAFTSMAN 10" ELECTRONIC RADIAL SAW
MODEL NOS. 113.197411 AND 113.197611 AND 113.197511
Always order by Part Number - Not by Key Number
FIGURE 4 - YOKE ASSEMBLY
Key
No
Part
No.
Description
Key
No
Part
No.
Description
1 815827 Actuator, Rip 20 109529 Nut, Square 5/8-11
2 STD600803 * Screw, Pan Rec. Hd 21 816988 Knob. Swivel
Type "T 8-32 X 3/8 22 STD541025 * Nut, Hex 1/4-20
3 815817 Nut, Square Lock 23 508155 Wrench, Adjustment w/Actuator
4 STD541462 * Nut, Lock 5/8-11 24 STD512515 * Screw, Pan Hd
5 62636 Nut, Square 1/4-20 1/4-20 X 1-1,'2
6 815693 Bracket, Rip Lock 25 STD551062 ‘Washer, .630 x 1-1/8x3/32
7 STD541425 * Nut, Lock 1./4-20 26 815680 Spring, Swivel
8 62520 Spacer 27 806828 Screw, Pan Hd
9 273229 Screw, Hex Hd Type "T" 1/4-20 X 1/2
Type ‘T" 1/4-20
X
1/2 28 815679-1 Pin Index
10 816497 Spring, Rip Lock 29 815694 Stud, Yoke Clamp
11 815671 Cam, Rip Lock 30 STD551031 ‘Washer, 21/64 X 5/8 X 1/32
12 818155 Lever, Rip Lock 31 63777 Bearing, Carriage
13 STD532510 * Bolt, Carriage 1/4-20 x 1 32 60438 Washer, No. 2 Carriage
14 STD541231 * Nut, Hex Jam 5/16-18 Bearing
15 STD551131 * Lockwasher, External 5/16 33 815807 Screw. Eccentric
16 815691 Ring, Yoke Index 34 81C214-3 Screw. Low Hd
17 STD551012 ‘Washer, 17,/64 x 7,/16 x 1/32 Cap 5/16-18 X 7/8
18 817398-1 Screw, Cap Locking 35 STD315485 * Bearing, Ball .3150 I.D.
1/4 20 X 5/8 36 817181 Wiper, Track
19 818207 Yoke 37 815689 Carriage
Standard Hardware Item may be Purchased Locally,
91
