C H A P T E R
7-1
Cisco TelePresence System 3200
OL-14521-01
7
Building the Second Row Table Assembly
Revised: October 29, 2009, OL-14521-01
Table Numbering Information Used in This Chapter
The table tops and privacy panels are numbered to assist you in installation. Your tabletops and privacy
panels use one of the following numbering schemes:
• Tabletops are numbered section 1 to section 7. The numbering scheme counts tabletop sections
starting from the center of the assembly. There are two tabletops that use section 5; if the two
sections are differentiated, they are labeled “section 5 right” and “section 5 left”.
Note The directions left and right refer to the assembly as you face the displays.
• Tabletops are numbered section 1 to section 8. The numbering scheme counts tabletop sections from
the right to the left.
Use the numbering scheme that is printed you your tabletops and privacy panels to perform this
procedure. Both methods of numbering are listed in this chapter and are included in the figures and
assembly steps.
Parts List
Key Part Description Part Number Qty Ctn Notes
1 Tabletop leg base 800-28454-xx 7 52-
54
2 Metal packaging brace 700-24275-xx 7 41-
43,
57
3 Molded foam bumper 800-28625-xx 7 41-
43,
57
4 Gutter and privacy panel support bracket,
type 1 700-27280-xx 2 50
