Cisco TelePresence System 3200
OL-14521-01
Chapter 6 Building the First Row Table Assembly
Parts List
Note
Steps for routing and connecting the microphone extension cables from the audio/video extension unit
and codec to the microphones are in
Chapter 9, “Routing Power and Signal Cables.”
Figure 6-13
Microphone Assembly
Step 14
Attach the table door to the tabletop sections and attach the “please close” label to the underside of the
table door.
204177
27
28
26
