9-2
Cisco TelePresence System 3200
OL-14521-01
Chapter 9 Routing Power and Signal Cables
Power Requirements for the Cisco TelePresence 3200
Caution Do not power on the PDUs until you route and connect all the cables.
Caution Use care when you route the power cables from the PDUs. Do not bend the cables immediately after they
exit the PDUs and be sure that the cable does not pull on, or cause any strain to, the PDU socket and
power cord plug connection. Incorrectly routed cables can cause undue stress to the PDU receptacle and
the power cord plug.
Warning Overcurrent protection is provided by branch circuit protection rated 20A.
Warning Output receptacles cannot exceed 15A for any one receptacle.
Power Requirements for the Cisco TelePresence 3200
Table 9-1 provides the power requirements and PDU locations for the Cisco TelePresence 3200 system.
Caution Correct routing of the various power cords to the PDUs and auxiliary control unit is critical for the safety
and success of the Cisco TelePresence 3200. Route each power unit to a different 20 amp circuit to
prevent circuit overload when all the electrical components are properly installed.
Table 9-1 PDU and Auxiliary Control Unit Locations and Power Requirements
Left PDU 1
(Located on Left Accessory Cabinet)
AC wall outlet
20 amps @100-120volts
or 10 amps @ 230-240 volts
Right PDU
(Located on Right Accessory Cabinet)
AC wall outlet
20 amps @100-120volts
or 10 amps @ 230-240 volts
Auxiliary Control Unit
(Located on rear of display structure)
AC wall outlet
20 amps @100-120volts
or 10 amps @ 230-240 volts
First Row Table PDU
(Located above the projector under the Center table segment)
AC wall outlet
20 amps @100-120volts
or 10 amps @ 230-240 volts
Second Row Table left-center PDU 20A AC wall outlet
Second Row Table right-center PDU 20A AC wall outlet
