10-8
Cisco TelePresence System 3200
OL-14521-01
Chapter 10 First-Time Setup
Setting Up CTS Components
Figure 10-3 Camera Target Assembly
Step 2 Attach the large target to the underside of the center table section by placing the round pads on the
underside of the clamps into recesses that are drilled under the table.
Tip You can feel under the table to find the small round recesses.
6
6
6
5
4
201192
