7-2
Cisco TelePresence System 3200
OL-14521-01
Chapter 7 Building the Second Row Table Assembly
Parts List
5 Gutter and privacy panel support bracket,
type 2 700-27279-xx 5 50
6 Gutter panel, section 1 (section 5) 800-31126-xx 1 50
7 Gutter panel, section 2 (section 4) 800-31129-xx 1 50
8 Gutter panel, section 3 (section 6) 800-31131-xx 1 50
9 Gutter panel, section 4 (section 3) 800-31133-xx 1 50
10 Gutter panel, section 5 (sections 2 and 7) 800-31124-xx 2 50
11 Privacy panel hanger 700-27311-xx 14 50
12 Floating bracket, type 1 700-27282-xx 2 50
13 Floating bracket, type 2 700-27281-xx 2 50
14 Tabletop: section 1 (section 5) 95-9995-01
Kit # 74-5565-01
1 26
15 Tabletop: section 2 (section 4) 95-10096-01
Kit # 74-5600-01
1 26
16 Tabletop: section 3 (section 6) 95-10097-01
Kit # 74-5601-01
1 26
17 Tabletop: section 4 (section 3) 95-10098-01
Kit # 74-5602-01
1 26
18 Tabletop: section 5 (sections 2 and 7) 95-9994-01
Kit # 74-5562
2 26 Some tabletop sections are marked
“5 left” and “5 right”; install the sections
so that the tabletop grain is correctly
matched.
19 Tabletop end, left (section 6) 95-10099-01
Kit # 74-5603-01
1 26
20 Tabletop end, right (section 7) 95-10100-01
Kit # 74-5604
1 26
21 Tabletop end brace 700-27413-xx 2 50
22 Privacy panel alignment bracket,
section 1 (section 5) 700-27275-xx 1 50
23 Privacy panel alignment bracket,
section 2 (section 4) 700-27276-xx 1 50
24 Privacy panel alignment bracket,
section 3 (section 6) 700-27277-xx 1 50
25 Privacy panel alignment bracket,
section 4 (section 3) 700-27278-xx 1 50
26 Privacy panel alignment bracket,
section 5 (sections 2 and 7) 700-27274-xx 2 50
27 Privacy panel, section 1 (section 5) 800-31112-xx 1 50
28 Privacy panel, section 2 (section 4) 800-31116-xx 1 50
29 Privacy panel, section 3 (section 6) 800-31117-xx 1 50
30 Privacy panel, section 4 (section 3) 800-31119-xx 1 50
Key Part Description Part Number Qty Ctn Notes
