Cisco TelePresence System 3200
OL-14521-01
Chapter 8 Assembling the Remaining Cisco TelePresence Elements
Parts List
Note
Note that the key numbers restart for each element.
Caution
Some system components have metal and plastic edges with hard angles. These edges are exposed until
you complete system assembly. Use caution when you move around the system during assembly to avoid
contact with any exposed system edges.
Warning
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Note
The directions left and right refer to the assembly as you face it from the front.
4
Vertical bar
700-23961-xx
2
32
5
Horizontal bar
700-23960-xx
2
32
6
M4 x 20 mm screws
48-0654-xx
4
1
Switch Bracket
Note
There are two additional brackets included with the accessory cabinet in Carton 33: 700-23338-xx and
700-23344-xx. These brackets attach the optional Ethernet switch to the left accessory cabinet. If you ordered this
switch, refer to the Cisco TelePresence System Hardware Options & Upgrade Guide to install the switch.
Key
Part Description
Part Number
Qty
Ctn
Notes
