12-34
Cisco TelePresence System 3200
OL-14521-01
Chapter 12 Field-Replaceable Unit Guide
Replacing a Second Row Table Top Section
Step 12 Move one of the table legs to allow access to the draw bolts or cam locks and remove the draw bolts or
cam locks from the adjoining table top sections. See
Chapter 7, “Building the Second Row Table
Assembly” for the location of the draw bolts or cam locks.
Note Make sure that the leg still supports both table top sections.
Step 13 If you are replacing an end piece, remove the attachment plates.
Step 14 If required, reposition the table leg so that it fully supports both table sections.
Step 15 Move the table leg on the other side of the table top to allow access to the draw bolts or cam locks and
remove the draw bolts or cam locks from the adjoining table top sections.
Note Make sure that the leg still supports both table top sections.
Step 16 Separate the table top sections to create a space between the section to be replaced of approximately one
inch (2.5 centimeters); this step allows you to remove the splines between the table top sections.
Tip To ease movement of the sections, you can place furniture sliders under each table leg before you move
the sections.
Caution Be sure that the legs support all table top sections and do not allow any of the sections to fall to the
ground.
Step 17 Remove the splines from the slot in the edges of the table top section.
Step 18 Remove the table top section to be replaced.
Step 19 Place the new table top section on the table legs.
Step 20 Place the splines in the slots on the edge of the new table top section.
Step 21 Press the table top sections together.
Step 22 Insert the draw bolts or cam locks and tighten them between the new table top section and the adjoining
table top sections. See
Chapter 7, “Building the Second Row Table Assembly” for the location of the
draw bolts or cam locks.
Step 23 If you are replacing an end piece, insert and attach the attachment plates.
Step 24 Attach the legs to the table top sections with the screws. See Chapter 6, “Building the First Row Table
Assembly” for the location of the table legs and screw attachment locations.
Step 25 Attach the gutter and privacy panel support brackets to the table assembly.
See Chapter 7, “Building the Second Row Table Assembly” for the gutter and privacy panel support
bracket attachment points and screw locations.
Step 26 Attach the gutter panel for the table top section.
See Chapter 7, “Building the Second Row Table Assembly” for the gutter panel attachment points and
screw locations.
Step 27 Attach the floating bracket on each side of the table top section.
See Chapter 7, “Building the Second Row Table Assembly” for the floating bracket attachment points
and screw locations.
