Cisco TelePresence System 3200
OL-14521-01
Chapter 12 Field-Replaceable Unit Guide
Replacing a First Row Table Top Section
Removing and Replacing a First Row Table Top Section
Step 1
Open the table door.
Step 2
Perform the following actions for specific first-row table top sections:
•
If you are replacing the table door or the left-center table top section, remove the table door. See
for an exploded diagram of the parts for the door.
•
If you are replacing the center table top section, remove the projector. See
for an
exploded diagram of the projector assembly.
Step 3
Detach the microphone from the table top section to be replaced. See
for an exploded
diagram of the microphone and its attachment hardware.
Step 4
Disconnect the microphone from the audio/video extension unit, route the cable through the table top
section, and remove the microphone.
Step 5
Remove the privacy panel from the table top section to be replaced.
Tip
Chapter 6, “Building the First Row Table Assembly”
has exploded drawings of the privacy panels.
Step 6
Remove the screws from the table legs that support the table top section.
Step 7
Move one of the table legs to allow access to the draw bolts or cam locks.
Note
Make sure that the leg still supports both table top sections.
Step 8
Remove the draw bolts or cam locks between the table top sections on the side that you moved. See
Chapter 6, “Building the First Row Table Assembly”
for the location of the draw bolts or cam locks.
Step 9
If required, reposition the table leg so that it fully supports both table sections.
Step 10
Move the table leg on the other side of the table top to allow access to the draw bolts or cam locks,
making sure that the leg still supports both table top sections.
Step 11
Remove the draw bolts or cam locks between the table top sections on the side that you moved.
Step 12
Separate the table top sections to create a space between the section to be replaced of approximately one
inch (2.5 centimeters); this step allows you to remove the splines between the table top sections.
Tip
Move the sections to the left and use the space created by the open table door.
Caution
Be sure that the legs support all table top sections and do not allow any of the sections to fall.
Step 13
Remove the splines from the slot in the edges of the table top section.
Step 14
Remove the table top section from the table legs.
Step 15
Place the new table top section on the table legs.
Step 16
Place the splines in the slots on the edge of the new table top section.
Step 17
Press the table top sections together.
