Contents
iv
Cisco TelePresence System 3200
OL-14521-01
C H A P T E R
9 Routing Power and Signal Cables 9-1
Parts List 9-1
Power Requirements for the Cisco TelePresence 3200 9-2
C H A P T E R
10 First-Time Setup 10-1
Parts List 10-1
Loading CTS Administration Software 10-1
Configuring an Alternate TFTP Server (Optional) 10-4
Setting Up CTS Components 10-4
Setting Up the Displays 10-5
Setting Up the Cameras 10-6
Starting the Software Setup 10-7
Adjusting the Zoom 10-9
Focusing the Camera 10-12
Attaching the Camera Hood Assembly 10-15
Setting Up the Speakers 10-18
Setting Up the Microphones 10-18
Setting Up the Projector 10-20
Troubleshooting Presentation Devices 10-22
Other Devices 10-23
C H A P T E R
11 Use & Care Guide 11-1
Maintaining the Tabletop 11-1
Cleaning the Plasma displays 11-1
Cleaning the Camera lens 11-2
Maintaining the Projector 11-2
C H A P T E R
12 Field-Replaceable Unit Guide 12-1
Complete List of Spares for the Cisco TelePresence System 3200 12-1
Powering On the System 12-4
Replacing the Camera Cluster—Part Number CTS3K-CAM-CLST-G2= 12-5
Required Information, Tools, and Equipment 12-5
Removing and Replacing the Camera Cluster 12-5
Replacing a Plasma Display—Part Number CTS-DISP-65-GEN4= 12-6
Required Information, Tools, and Equipment 12-6
Removing Audio Components 12-7
Removing the Camera Cluster 12-8
Removing the Left Door 12-8
