Cisco 3200 User Manual
Page 125
7-37
Cisco TelePresence System 3200
OL-14521-01
Chapter 7 Building the Second Row Table Assembly
Parts List
Figure 7-38
Microphone Assembly
Step 39
Lift the privacy panel for table section 1 (section 5) into position until it seats on the locating pins on the
table assembly; then, use the plastic knob screws to loosely attach the privacy panel from below.
Note
Do not fully tighten the screws until you attach all privacy panels. You perform final spacing adjustments
after you attach the last panel.
204180
52
53
51
