12-21
Cisco TelePresence System 3200
OL-14521-01
Chapter 12 Field-Replaceable Unit Guide
Replacing a Microphone—Part Number CTS-MIC=
c.
Alternately, if the fit is too tight to remove in this manner, remove the mounting screws from the
tabletop. Ensure the projector assembly is secured while removing the screws.
See
Chapter 6, “Building the First Row Table Assembly”
and
Chapter 7, “Building the Second Row
for more information.
Step 3
Disconnect the microphone from the microphone extension cable.
The microphone has a cable that is approximately three feet (1 meter) in length.
Step 4
From the underside of the tabletop, remove the two screws and washers that secure the microphone.
Note
Retain the screws and washers.
Step 5
Pull the microphone cable through the hole in the table and set the microphone aside.
Step 6
Route the cable for the replacement microphone through the hole in the tabletop.
Step 7
From the underside of the tabletop, attach the microphone using the screws and washers.
Step 8
Connect the microphone extension cable to the microphone.
Step 9
Power on the system by turning the power switches to the On position on the two left PDUs, single right
PDU, and (if present) auxiliary control unit or PDU on the rear center of the display assembly.
Step 10
Open a browser on a computer connected to the network.
Step 11
Type in the IP address of the Primary codec. Enter the required information at the login screen. The
Cisco TelePresence Administrator window appears.
Step 12
Verify the status of the Cisco Unified Communications Manager (seen in the lower left portion of the
window) is Enabled/Up.
Step 13
Select Hardware Setup to verify the cameras, displays, speakers, and microphones are working
properly.
Refer to the
your software release for more
information.
Step 14
If required, reattach the projector assembly.
See
Chapter 8, “Assembling the Remaining Cisco TelePresence Elements”
for more information.
Step 15
Perform the microphone test to verify that the microphone is working properly.
See the
“Setting Up the Microphones” section on page 10-18
for more information.
