C H A P T E R
10-1
Cisco TelePresence System 3200
OL-14521-01
10
First-Time Setup
Revised: October 31, 2012, OL-14521-01
After you have assembled the Cisco TelePresence System (CTS), you set up the individual system
components (such as displays and cameras) using Hardware Setup, located under Troubleshooting in
the CTS Administration software. This chapter explains how to initially set up CTS components and
contains the following sections:
• Loading CTS Administration Software, page 10-1
• Setting Up CTS Components, page 10-4
Note You cannot perform diagnostics during an active Cisco TelePresence system call.
Parts List
Loading CTS Administration Software
CTS Administration Software is factory-installed on each codec and loads during initial bootup.
To load CTS Administration Software:
Step 1 Turn on the Auxiliary Control Unit.
Step 2 Power on the three PDUs in that are located on the accessory cabinets and the single PDU that is
underneath the first row table (near the projector).
Key Part Description Part Number Qty Ctn Notes
Camera Hood Assembly ( Figure 10-12 )
1 Camera assembly 800-30872-01
68-3277-01
1 2
2 Camera hood cover: top 1 2
3 Camera hood cover: bottom 1 2
7 M4 x 12mm Pan Head screws, black 48-2426-01 2 N/A
