3-23
PFC-6075R • 5403594 • REV D • 9/14
For a Single Device:
1. From the SLC Addr Prog menu, press 1 to address a Single device.
2. Attach connector wires to SLC PGM terminals, if not already done. The “Connect Device” prompt displays.
3. Connect device. The “Found Address: xx” prompt displays.
y y Modify new address, if needed, or press ENTER to continue.
y y The “Writing Addr: XX” prompt displays, and the system beeps three (3) times when completed.
When addressing is completed, the “Found Addr: XX, New Addr: XX” prompt displays.
y y Disconnect device, and continue with next device.
y y Repeat steps, as needed.
4. Press ESC when finished.
For Multiple Devices:
1. From the SLC Addr Prog menu, press 2 to address Mult device.
•y The “Start Address: XX” prompt displays.
•y Modify starting address, if needed, and press ENTER.
•y The prompt “Connect Device” displays.
2. Connect 1 st device. The “Addr = XX Next = XX Remove” prompt displays.
•y Disconnect the device, connect next device. Addressing is completed when the panel emits a series of three (3) beeps.
•y The “Addr = XX Next = XX Remove” prompt displays.
•y Continue with next device, following prompts.
Notes:
•y The prompt “Addr = XX” refers to the current device number, and “Next = XX” is the next sequential address number.
•y When configuring a Class B DCM-4, press the UP ARROW to skip the next sequential number. The Class B DCM-4
requires 2 addresses; if this isn't done, the next available address will be assigned to a different device and the DCM-4
will operate as a single point device.
3. Press ESC when finished.
