IFS NS3502-8P-2S User Manual

505

NS3502-8P-2S:/> QoS Storm multicast enable 2


QoS QCL Add

Description:

Add or modify QoS Control Entry (QCE).
If the QCE ID parameter is specified and an entry with this QCE ID already exists, the

QCE will be modified. Otherwise, a new QCE will be added. If the QCE ID is not specified, the
next available QCE ID will be used. If the next QCE ID parameter is specified, the
QCE will be placed before this QCE in the list. If the next QCE ID is not specified and if it is a new
entry added, the QCE will be placed last in the list. Otherwise if the next QCE ID is not specified
and if existing QCE is modified, QCE will be in the same location in the list. To modify and move
the entry to last in the list, use the word 'last' for .


Syntax:

QoS QCL Add [] [] [] [] [] [] [] []

[] [(etype []) | (LLC [] [] []) | (SNAP []) | (ipv4
[] [] [] [] [] []) | (ipv6 [] []
[] [] [])] [] [] []


Parameters:

: QCE ID (1-256), default: Next available ID
: Next QCE ID: "next_id (1-256) or 'last'"
: Port List: "port or 'all'", default: All ports
: Frame tag: untag|tag|any
: VID: 1-4095 or 'any', either a specific VID or range of VIDs
: Priority Code Point: specific(0, 1, 2, 3, 4, 5, 6, 7) or
range(0-1, 2-3, 4-5, 6-7, 0-3, 4-7) or 'any'
: Drop Eligible Indicator: 0-1 or 'any'
: Source MAC address: (xx-xx-xx) or 'any', 24 MS bits (OUI)
: Destination MAC type: unicast|multicast|broadcast|any
etype : Ethernet Type keyword
: Ethernet Type: 0x600-0xFFFF or 'any' but excluding 0x800(IPv4) and

0x86DD(IPv6)

llc : LLC keyword
: Destination Service Access Point: 0x00-0xFF or 'any'
: Source Service Access Point: 0x00-0xFF or 'any'
: LLC control: 0x00-0xFF or 'any'
snap : SNAP keyword
: Protocol ID (EtherType) or 'any'
