IFS NS3502-8P-2S User Manual

202

Conflict

Displays QCE status. It may happen that resources required to
add a QCE may not available, in that case it shows conflict status
as 'Yes', otherwise it is always 'No’. Please note that conflict can
be resolved by releasing the resource required by the QCE and
pressing 'Refresh' button.

Action

Indicates the classification action taken on ingress frame if
parameters configured are matched with the frame's content.
There are three action fields: Class, DPL and DSCP.
Class: Classified QoS Class; if a frame matches the QCE it will be
put in the queue.
DPL: Drop Precedence Level; if a frame matches the QCE then DP
level will set to value displayed under DPL column.
DSCP: If a frame matches the QCE then DSCP will be classified
with the value displayed under DSCP column.

Modification
Buttons

You can modify each QCE in the table using the following
buttons:

: Inserts a new QCE before the current row.
: Edits the QCE.
: Moves the QCE up the list.
: Moves the QCE down the list.
: Deletes the QCE.
: The lowest plus sign adds a new entry at the bottom of the

list of QCL.


Buttons

: Click to refresh the page. This will help to check the latest conflict status after releasing the

resources.

4.9.11.1 QoS Control Entry Configuration

The QCE Configuration screen in

Figure 4-9-14

appears.
