IFS NS3502-8P-2S User Manual
256
These setting are common for all of the Authentication Servers.
Object
Description
• Timeout
The Timeout, which can be set to a number between 3 and 3600
seconds, is the maximum time to wait for a reply from a server.
If the server does not reply within this timeframe, we will
consider it to be dead and continue with the next enabled server
(if any).
RADIUS servers are using theprotocol, which is unreliable by
design. In order to cope with lost frames, the timeout interval is
divided into 3 subintervals of equal length. If a reply is not
received within the subinterval, the request is transmitted again.
This algorithm causes the RADIUS server to be queried up to 3
times before it is considered to be dead.
• Dead Time
The Dead Time, which can be set to a number between 0 and
3600 seconds, is the period during which the switch will not send
new requests to a server that has failed to respond to a previous
request. This will stop the switch from continually trying to
contact a server that it has already determined as dead.
Setting the Dead Time to a value greater than 0 (zero) will enable
this feature, but only if more than one server has been
configured.
RADIUS Authentication Server Configuration
The table has one row for eacAuthentication Server and a number of columns, which are:
Object
Description
• #
The RADIUS Authentication Server number for which the
configuration below applies.
• Enabled
Enable the RADIUS Authentication Server by checking this box.
• IP
Address/Hostname
The IP address or hostname of the RADIUS Authentication Server.
IP address is expressed in
• Port
Thport to use on the RADIUS Authentication Server. If the
port is set to 0 (zero), the default port (1812) is used on the
RADIUS Authentication Server.
• Secret
The secret - up to 29 characters long - shared between the
