Example:
Set the default DEI for an untagged frame in 1 for port1.
NS3502-8P-2S:/>qos Port Classification dei 1 1
QoS Port Classification Tag
Description:
Set or show if the classification is based on the PCP and DEI values in tagged frames.
Syntax:
QoS Port Classification Tag [] [enable|disable]
Parameters:
: Port list or 'all', default: All ports
enable : Enable tag classification
disable : Disable tag classification
(default: Show tag classification mode)
Default Setting:
disable
Example:
Enable QoS port classification Tag.
NS3502-8P-2S:/>qos Port Classification tag 1-10 enable
QoS Port Classification Map
Description:
Set or show the port classification map.
This map is used when port classification tag is enabled,and the purpose is to translate the
Priority Code Point (PCP) and Drop Eligible Indicator (DEI) from a tagged frame to QoS class and
DP level.
Syntax:
