Honeywell Bendix/King AV8OR Ace User’s Guide
Aviation Mode Operation
D200904000003
Page 2-38
Rev 3 Mar 2012
©
Honeywell International Inc. Do not copy without express permission of Honeywell
Altitude (feet)
Filled
>= +250
>= -250
Red
50%
-250 to +249
-750 to –251
Yellow
50%
-750 to –251
-1250 to –751
Yellow
25%
-1250 to –751
-17500 to –1251
Dark
Green
/Dark
Yellow
50%
-2000 to –1251
< -2000 to -1751
Dark
Green
100%
< -2000
< -2000
Black
100%
o
At ranges of 200 nm and less, areas not covered by
the terrain database are displayed using a 50 % red
dithered pattern.
o
The Relative Terrain Map is rotated and scaled
consistent with the current map location, orientation
and range.
o
When terrain data is scaled for display, the highest
elevation is used for each location to determine its
color.
o
The 0.5 nm radius circles around obstacles are
displayed only if their radii after scaling are large
enough to be shown.
o
If altitude information is not available then a warning
message is displayed on the map image with the text
“No Altitude Available. Relative Terrain Not Displayed.”
