Honeywell Bendix/King AV8OR Ace User’s Guide
Getting Started
D200904000003
Page 1-4
Rev 3 Mar 2012
©
Honeywell International Inc. Do not copy without express permission of Honeywell
FIG.
NO
DISPLAY OR
CONTROL
DESCRIPTION
7
Zoom In/Zoom Out
Zooms in or zooms out 1
step each time the hard key
is pressed. Hold down the
hard key to do multiple
steps.
8 Removable
battery
cover
A replaceable battery is
included with the unit. An
optional battery with a longer
life is also available. The
serial number for the unit is
located on the case under
the battery.
9
Direct To
Starts the Direct To function.
Refer to the
TO Navigation section on
page 2-59.
10
View
The View hard key cycles
between the Map, Weather
and Chart pages and other
user selectable views.
11
MENU key
The MENU hard key returns
the user to the main menu
from any program in the unit.
12 External
GPS
antenna jack
The remote GPS antenna
jack allows the user to plug
in the remote GPS antenna
that is supplied with the unit
for better satellite reception.
13
Stylus
The stylus allows the user to
precisely tap the touch
screen.
