Honeywell Bendix/King AV8OR Ace User’s Guide
D200904000003 Aviation Mode Operation
Rev 3 Mar 2012 Page 2-179
© Honeywell International Inc. Do not copy without express permission of Honeywell
CREATING A NEW WEIGHT AND BALANCE PROFILE
Use the following order of entry to create a new Weight and Balance
profile for an aircraft.
1. Select the Profile tab and enter data for all of the fields.
2. Select the Envelope tab and enter the weight and the arm for
each of the envelope points that was entered in the Profile tab
for step 1.
3. View the C.G. Graph page and the Layout page and make sure
that they match your aircraft flight manual Type Certificate.
4. Select the Data Entry Tab and enter the Arm for each row that
shows. (Rows were defined in the Profile page)
5. Tap on the FILE soft key to save or create a new weight and
balance file. An Aircraft Profile pop up window shows. If no
Weight and Balance file has been created yet, only the
CLOSE
and the NEW FILE soft keys show. If a file has already been
created, SAVE , LOAD and DELETE soft keys also show.
6. Tap on the NEW FILE soft key and enter the name of the new
aircraft profile into the data entry screen. Tap on the “Enter” key
to accept the aircraft profile name.
7. Tap on the SAVE soft key and the OK soft key to save the new
aircraft profile.
8. Tap the CLOSE soft key to return to the main Weight and
Balance page.
Multiple Weight and Balance aircraft profiles can be created for
different aircraft. After the aircraft profiles are created, use the
FILE
soft key that shows on the “Data Entry”, “Profile” or “Envelope” tabs
on the Weight and Balance screen to display the “Aircraft Profile”
