VFR MOVING MAP FUNCTION
The AV8OR ACE features a real-time moving map that can do much
more than just plot your course. The core capability of AV8OR ACE
MAP mode function is its intuitive mapping and navigation function,
which is capable of displaying highly detailed, vectored (point and
line) maps. This detailed vector data includes roads data, street
address data, airspace boundaries, airports, Navigational Aid
(NAVAID)s, lakes, rivers, coastlines, cities, highways and terrain
elevation data used to help situational awareness.
Map Display Window
On the Aviation Main Menu, tap on the
soft key to display
the Map page as shown below.
