Honeywell Bendix/King AV8OR Ace User’s Guide
Aviation Mode Operation D200904000003
Page 2-18 Rev 3 Mar 2012
© Honeywell International Inc. Do not copy without express permission of Honeywell
•
Lightning: If lightning strike data is available, lightning strike
icons are displayed on the page.
•
Precip Type: If precipitation type data is available, the
precip type icon is displayed on the page.
•
Nexrad Coverage : If Nexrad coverage is available, it is
displayed on the page.
•
Cloud Top: If cloud top data is available, it is displayed on
the page.
•
Storm Cell: If storm cell data is available, it is displayed on
the page.
The table below show which overlays are available for each primary
map: An “X” in the column indicates that the overlay is available for
the primary page at the top of the column
Table 2-1: Image Overlays on Primary Maps
OVER-
LAY TOPO
ON
MAP TOPO
OFF
MAP NEXRAD
MAP METAR,
PIREP,
WINDS
ALOFT
MAPS AIRMET,
SIGMET
MAPS
Flight
Plan X X X X X
Traffic X X X X X
Flight
Log
Trail X X X X X
