Honeywell Bendix/King AV8OR Ace User’s Guide
D200904000003 Getting Started
Rev 3 Mar 2012 Page 1-7
© Honeywell International Inc. Do not copy without express permission of Honeywell
Optional Equipment
The following accessories are available for the AV8OR:
Table 1-3 Optional Equipment
ITEM
PART NUMBER DESCRIPTION
1 005-03702-1011 External TMC Antenna
2 005-03702-1008 Automobile Dashboard Mount (Bean
Bag)
3 005-03702-1017 Single RS 232 Serial Cable (90 degree
10 pin mini USB to single DB9 male
connector)
4 005-03702-1027 Dual RS232 Serial Cable (90 degree
10 pin mini USB to dual DB9 male
connectors)
5 005-03702-1026 AV Input cable
6 005-03702-1028 USB Host Cable
7 005-03702-1006 External GPS Antenna with 90 degree
connector
NOTE: The list of optional equipment may change in the future. For
the latest list of options or to order a part, please visit the
bendixking.com/av8or website.
Charging the internal battery
Before using this unit for the first time or when replacing the internal
battery with a new battery, the internal battery in the AV8OR ACE
must be charged.
Find the power connector (7) on the right side of the unit. Refer to
Figure 1-4 .
Recharge the unit by either using the DC power adapter or the
120/220V AC adapter.
The LED charging indicator (4) on the unit shows a yellow light while
the unit is charging.
When the unit is completely charged, the yellow light changes to a
green light. If the unit is turned on while charging, the charging
animation in the top right portion of the screen also displays a green
battery with full bars.
The table below shows the different charge levels.
