Honeywell Bendix/King AV8OR Ace User’s Guide
D200904000003 Appendix
Rev 3 Mar 2012
Page 6-9
© Honeywell International Inc. Do not copy without express permission of Honeywell
MINI USB/SERIAL PORT
The mini USB/serial port on the side of the AV8OR ACE has the
follow pin-outs:
Table 6-2: Mini USB Connections
Pin Number Signal Description
1 RS 232 Port #1 TX RS 232 Port #1 TX
2 VCC (USB 5V)
3 RS 232 Port #1 RX RS 232 Port #1 RX
4 USB Data -
5 RS232 Det Ground pin to allow Port
#2 to be internally
connected to the RS232
transceiver
6 USB Data +
7 RS 232- Port #2 TX RS 232 Port #2 TX
(debug)
8 USB ID
9 RS 232- Port #2 RX RS 232 Port #2 RX
(debug)
10 Ground
NOTE 1: Pins 2, 4, 6, 8 and 10 are standard USB Mini-B pins and
allow a standard USB Mini-B device to connect to the
AV8OR Ace.
NOTE 2: The AV8OR ACE provides two RS 232 interfaces through
the Mini USB/serial port. To use only one of the RS-232
interfaces, use the optional RS232 Serial or one side of
the RS232 dual serial cable. To use two RS-232
interfaces at the same time, use the optional dual RS232
serial cable. Refer to the
Supplied Equipment section on
page 1-6 for the part numbers of the optional RS232
cables. The single and dual RS232 cables can be ordered
from bendixking.com/av8or.
