Honeywell Bendix/King AV8OR Ace User’s Guide
D200904000003 Automotive Mode Operation
Rev 3 Mar 2012 Page 3-21
© Honeywell International Inc. Do not copy without express permission of Honeywell
Icon Type More information
Time
information There are time values that can be
shown: • Current GPS time
•
Time remaining to reach the
destination • Time remaining to
reach the next via point
•
Estimated arrival time at the
destination
•
Estimated arrival time at the next
via point
Distance
information There are distance type values that
can be shown:
•
Distance remaining to reach the
destination
•
Distance remaining to reach the
next via point • Current altitude
The next area is a combined status field. Tap this area to open the
Quick menu (refer to Figure 3-13: Quick Menu).
.
Icon Status
for More information
GPS
position
quality The more lit bars, the better is the GPS
position.
Battery
status The device is running on battery power.
The number of lit bars represent the
remaining capacity.
The
battery
is being
charged The device is running on external power.
The battery is being charged.
