Honeywell Bendix/King AV8OR Ace User’s Guide
Aviation Mode Operation D200904000003
Page 2-72 Rev 3 Mar 2012
© Honeywell International Inc. Do not copy without express permission of Honeywell
CENTER MAP soft key is shown as an option on the Pointer
Menu .
The CENTER MAP option is tapped to center the map on the PTR
position on the map.
Tap on the CLEAR PTR to return clear the PTR position and center
the aircraft on the map. The PTR position will remain centered on the
Map for a period of time and then the Map page changes to show
the aircraft position centered on the Map.
Center To WPT/Center Aircraft
After any kind of navigation was activated, in Non-Pointer mode, the
CENTER TO WPT soft key is shown for the user to view the WPT
position on the map.
Figure 2-69: Map – Center to Waypoint
The CENTER TO WPT soft key changes to a CENTER AIRCRAFT
soft key after the CENTER TO WPT soft key is tapped.
