Honeywell Bendix/King AV8OR Ace User’s Guide
D200904000003 Getting Started
Rev 3 Mar 2012 Page 1-3
© Honeywell International Inc. Do not copy without express permission of Honeywell
Displays and Controls
The table below describes the AV8OR ACE displays and controls
that are displayed in Figure 1-1:
Table 1-1 Displays and Controls
FIG.
NO
DISPLAY OR
CONTROL
DESCRIPTION
1 Touch screen 7 inch TFT Active Matrix
LCD screen. The resolution
is 800 x 480 pixels.
2 LED charging status
indicator
Shows the status of the
charging system while the
unit is being charged.
3 Portrait/Landscape
Icon
Tap the Portrait/Landscape
Icon to switch between
portrait and landscape
modes.
4 SD slot and SD card The SD slot holds a SD card
which contains the aviation
and automotive navigation
software.
5 Volume control knob The volume control controls
the volume of the sound
through the rear speaker or
the Headset jack if a headset
is plugged in.
6 POWER key The POWER key is used to
turn the unit on and off and
also can put the unit into
Sleep mode and wake the
unit from Sleep mode.
