Honeywell Bendix/King AV8OR Ace User’s Guide
D200904000003 Aviation Mode Operation
Rev 3 Mar 2012 Page 2-163
© Honeywell International Inc. Do not copy without express permission of Honeywell
the 2 minute turn tick marks when executing a 2 minute turn and
align with the 0 tick marks when flying straight and level.
PANEL PAGE ACE PORTRAIT ORIENTATION
In portrait mode, the Panel page shows a split screen like
display with the gauges on the top and the moving map on the
bottom as shown in the figure below. The user selects which
map shows on the bottom half of the page.
The top half of the page is not pannable. The lower half of the
portrait Panel page is the active map. It is on the map that the
user will be able to pan and interrogate the symbols. The
Vertical Profile function is not available on this page.
