Trends
Propaq Encore Reference Guide 151 Welch Allyn
Trends
Trends Specifications
Display
Display Specifications
Characteristic Specification a
a.Assumes SpO
2
and CO
2
functions are present.
Model 202 Parameters NIBP, T1, T2,
∆
T, HR (heart rate/pulse rate), SpO
2,
End-tidal CO
2,
Inspired CO
2
, Breath Rate
Model 204 Parameters NIBP, P1, T1, T2,
∆
T, HR (heart rate/pulse rate), SpO
2,
End-tidal CO
2
, Inspired CO
2
, Breath Rate
Model 206 Parameters NIBP, P1, P2, T1, T2,
∆
T, HR (heart rate/pulse rate), SpO
2 ,
End-tidal
CO
2
, Inspired CO
2
, Breath Rate
Duration 5 hours for non-NIBP trends (up to 150 readings)
A maximum of 128 readings (up to 8 hours) for NIBP trends
Resolution All channels except NIBP sample data at 2-minute intervals
For NIBP trends, a new entry is placed in the table each time an NIBP
determination is made.
Characteristic Specification
Matrix 552 x 256 pixels EL display
Active Viewing Area 145.75 mm x 67.56 mm
Pixel Size 0.203 mm x 0.203 mm
Pixel Pitch 0.264 mm x 0.264 mm
Character Height Large: 11.03 mm (0.434 in)
Medium: 7.34 mm (0.289 in)
Small: 3.64 mm (0.143 in)
Viewing Angle >160° Horizontal and Vertical
Contrast Ratio >45 (“On” pixel luminance/“Off” pixel luminance)
Display Color Amber
Display Background Color Black
“On” Pixel Luminance >9.0 fL (area of amber pixel; includes protective window)
“Off” Pixel Luminance <0.2 fL (black pixel)
Refresh Rate 109 Hz
