Synchronized Cardioversion Using the LIFEPAK 6s
Welch Allyn 134 Propaq Encore Reference Guide
5. Follow hospital procedures and LIFEPAK 5 instructions for cardioversion.
6. If subsequent cardioversion must be performed, repeat steps 3 through 5.
Synchronized Cardioversion Using the LIFEPAK 6s
1. Set up the LIFEPAK 6s defibrillator and any other instrumentation according to
institutional procedures or manufacturer’s operating instructions.
Warning If the R-wave synchronization markers do not appear to be nearly
simultaneous with the R-wave peaks on the Propaq Encore display or are not
present, do not proceed with synchronized cardioversion.
You must press the LIFEPAK 5’s SYNC button and check for appropriate
synchronization markers on the Propaq Encore before each attempt at
cardioversion. Welch Allyn cannot guarantee the delay from the sync marker
to the defibrillator discharge.
A fault in the cable between the Propaq Encore and the defibrillator, or
unplugging the cable, will prevent showing markers on the Propaq and can
prevent setting the defibrillator to synchronized mode.
The Physio-Control LP6s Defibrillator Sync Connector/Cover (Physio-Control
part number 801297-00) must be installed before you can connect it to the
Propaq Encore monitor.
mmHg
NIBP SETUP INV PRS SpO 2 /CO 2 ECG/RESP
MCO 2 BR
HR T 1 18:45:28
N
I
B
P
102.3
° F
SYS DIA MEAN
mmHg TIME SINCE READING: 10 min
35
135 81
12
88
NIBP
II
1
mV
cm
MON
(103)
(103)
135
81
SpO 2 99
Sync Markers for the LIFEPAK 5
and LIFEPAK 6s
