Printer Functions
Propaq Encore Reference Guide 35 Welch Allyn
Printer Functions
Press
SETUP
,
MORE
,
PRINTER
to display the printer menu and setup window.
NEXT Selects the next setting in the status window.
CHANGE Changes the currently selected display setting.
PR TREND
Prints all trends turned on in the Printer Trend Select Window.
MORE Pressing the MORE button displays another menu and status window.
PREV MENU Returns you to the previous menu.
CONTINUOUS Sets the print speed for real time (continuous) measurements to 6.25, 12.5,
or 25 mm/sec. This sets the print speed for a printout obtained by
pressing the
START/STOP button on the printer.
AUTO PRINT Automatically prints 8 seconds of patient information every 15
minutes, 30 minutes, 1 hour, 2 hours, or 4 hours. This is the latest
patient information (real time). The print speed is automatically set
to 25 mm/sec.
ALARM PRINT
Automatically prints upon an alarm. The Propaq Encore prints 20
seconds of patient information. The first 12 seconds contain
information prior to the alarm. The print speed is automatically set
to 25 mm/sec.
NIBP TICKET
Automatically prints an NIBP Ticket when the measurement is
taken.
APNEA TICKET
When turned on, an Apnea Ticket is printed at the conclusion of an
apnea alarm and at the one-minute clock interval if the apnea alarm
does not cease.
OXYCRG ON ALARM
When turned on, an oxycardiorespirogram will print if an HR/PR,
SpO
2
, or RR/BR alarm occurs. For more information on OxyCRG,
see page 112.
mmHg
NEXT MORE PREV MENU PR TREND CHANGE
MCO 2 BR
SpO 2
PA
ART
HR T 1 NIBP 18:45:28
III
1
mV
cm
MON
PRINTER SETUP PAGE
CONTINUOUS : 25.0 mm/s
AUTO PRINT : 15 minutes
ALARM PRINT :
OFF
NIBP TICKET : OFF
APNEA TICKET : OFF
OXYCRG ON ALARM: OFF
102.3
° F S 122
35/ 18
( 85)
35 12
92
122
58
80
