Removing the Defib Sync Interface from the LIFEPAK 5
Welch Allyn 132 Propaq Encore Reference Guide
2. Slide the Propaq Encore Defib Sync
interface onto the left side of the
LIFEPAK 5 until it snaps in place.
3. Connect the cable end to the Propaq’s
DEFIB SYNCHRO connector on the right
side panel.
Removing the Defib Sync Interface from the LIFEPAK 5
1. To remove the interface, disconnect the cable end from the Propaq Encore.
2. Press the lever on the side of the LIFEPAK 5 and
slide the interface forward until it is free from the
defibrillator.
3. Store the interface in its static-protected plastic bag
when not connected to the LIFEPAK 5.
