Press NET OFF to Disconnect from Acuity
Propaq Encore Reference Guide 117 Welch Allyn
Key-press Route to Acuity Menu
Press NET OFF to Disconnect from Acuity
When you want to disconnect the monitor from Acuity, be sure to use the
NET OFF
button as
described below. The NET OFF button is a safety feature to help make sure the patient is not
disconnected accidentally. If you simply disconnect the Acuity network cable from the
monitor without using the
NET OFF
button, the monitor and Acuity both generate equipment
alert messages that must be acknowledged by an operator.
1. To disconnect the Propaq Encore from the Acuity network, press the front panel NET
OFF
button.
Warning If you don’t set alarm limits, Acuity uses preset settings (for
arrhythmia limits), and the powerup default settings for the Propaq Encore.
When a Propaq Encore in Adult or Pediatric Mode is connected to an Acuity
System, the audio alarms at the bedside Propaq can be delayed up to 4
minutes and 15 seconds. The delay time is selected in Acuity software at the
time of Acuity installation. Visual alarm indications are not delayed.
FRZ PRNT
SETUP NIBP ECG/RESP INV PRS SpO2/CO2
SETUP MENU 1
MORE ALARMS TRENDS WAVE SEL STATSCALE
ACUITY
ACUITY MENU
PREV MENU SNAPSHOT NET OFF
MAIN MENU
FREEZE/
UNFREEZE
NET OFF
ART
( 85)
122
58
HR 80
NET OFF
When the monitor is connected to Acuity, pressing
this button disconnects the monitor from the
Acuity network.
FREEZE/UNFREEZE
When the monitor is NOT connected to Acuity,
pressing this button freezes or unfreezes the
displayed waveforms.
