In Ground Model 200iPX/250iPX Motorcycle Dynamometer Installation Guide
C H A P T E R 3
Air Brake
3-6
2 Remove the Button board.
2a
Remove the four screws securing the Button board to the control panel and
set aside.
2b Remove the Button board and set aside.
Figure 3-5: Remove the Button Board
3 Unscrew the black switch body nut and remove the switch body. Set the nut and
switch body aside.
Figure 3-6: Remove the Switch Body
button board
screw
switch body nut
switch body
