E - dyno preparation for upgrade installation – Dynojet 250iPX: Installation Guide User Manual
Page 151
In Ground Model 200iPX/250iPX Motorcycle Dynamometer Installation Guide
E-1
A
P P E N D I X
E
D
YNO
P
REPARATION
FOR
U
PGRADE
I
NSTALLATION
This appendix describes how to prepare an existing in ground dyno for installing the
iPX upgrade kit. To ensure safety and accuracy in the procedures, perform the
procedures as they are described.
