I N S T A L L A T I O N
Left Side Blower and Monitor Arm Installation
Version 2 In Ground Model 200iPX/250iPX Motorcycle Dynamometer Installation Guide
2-19
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LEFT SIDE BLOWER AND MONITOR ARM INSTALLATION
Use the following instructions to install the left side blower mount, monitor support,
and junction box along with the left blower assembly and monitor tray. The right
blower mount and assembly will be installed later.
You will need the following parts:
• 21221500 Blank Plate, Junction Box
• 21228000 Junction Box Base
• 26215520 Washer, 1/8", Poly, for Monitor Support (3)
• 35521420 Cap Plug, for Monitor Support (4)
• 61329100 Monitor Arm (2)
• 61329101 Monitor Tray
• 61329500 Monitor Support
The following parts are included in the Blower Assembly, P/N 76722005:
• 21600015
Lower Blower Arm
• 26215220 Washer, 3/8", Metal
• 26215520 Washer, 1/8", Poly (2)
• 26215521 Washer, 1/4", Poly (2)
• 35521420 Cap Plug (4)
• 35712991 Clamp Lever
• 37513200 Anchor, Redhead, 3/8" (4)
• 61328101 Blower Assembly
• 61329601 Blower Mount
• 63413001 Upper Blower Arm
• DM150-002-007 Washer, 5/16", Flat (4)
• DM150-019-012 Bolt, 3/8-16 x 1", Hex (4)
