In Ground Model 200iPX/250iPX Motorcycle Dynamometer Installation Guide
C H A P T E R 4
Basic CPI Operation
4-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BASIC CPI OPERATION
The control panel may be mounted to either side of the tray for easy access by the
dyno user while seated on the bike. The graphics on the control panel are grouped
together according to function and color coded for ease of identification.
A description of the functions and displays follows:
Figure 4-1: Control Panel Features
status indicator
light
