Dyno Drum Module Installation
Version 2 In Ground Model 200iPX/250iPX Motorcycle Dynamometer Installation Guide
2-5
screw, 8-32 x 3/8", pan-head,
phil (34)
P/N 36540643
iPX upgrade kit
P/N 77000004
shipped in a separate crate,
refer to page 2-12
screw, 1/4-20 x 5/8", pan-
head, torx (12)
P/N 36561045
standard carriage
P/N 78100004
or
extended carriage
P/N 78100005
bolt, 3/8-16 x 1/2", button-
head, flange, allen (16)
P/N 36580434
ground hook kit (2)
P/N 79190001
see list of parts below
washer, 3/8", splitlock,
steel (12)
P/N 36932100
power carriage
P/N 82943001
included on P/N 78100004
or 78100005
anchor, redhead, 3/8" (12)
P/N 37513200
banner, dynojet (2)
P/N D706
installation tool, redhead
anchor
P/N 37518200
inductive secondary
pickup (2)
P/N DE100-109S
woodruff key, 3/8 x 1-3/8"
P/N 37620622
inductive primary pickup
clip
P/N DE100-110L
cable harness wrap kit
P/N 43400000
washer, 5/16", flat (18)
P/N DM150-002-007
part description part description
