Dynojet 250iPX: Installation Guide User Manual
Page 66
In Ground Model 200iPX/250iPX Motorcycle Dynamometer Installation Guide
C H A P T E R 2
Routing Cables
2-44
5
Close the CPI front access panel. Refer to page 2-32.
Figure 2-35: Wire the Breakout Board
temp
load control
pick-up card
J2 J1
J1
J2
eddy current brake only or
eddy current brake and air
brake with control panel
air brake
only
